KYOCERA Precision Tools

Printed Circuit Board Catalog

View our extensive PCB cutting tool product line in one place

View Online Download PDF (5.9MB)

New 2020-2021 PCB Catalog!

PCB drilling, milling, routing, scoring, engraving, and countersink solutions


Try our new digital catalog!

  • Full indexable cutting tool product lineup
  • Quickly search part numbers, descriptions, and features
  • Extensive product dimensions and usage information
  • Downloadable images, drawings, and literature
  • Customizable filters for faster product navigation
  • Side-by-side product comparison features
  • The most up-to-date product information

Featured Products

OCT 2020

Series 430 Hybrid Flute Undercut Drills

Kyocera is pleased to introduce its new hybrid undercut drill with a unique 2-into-1 hybrid flute design. This high-strength design demonstrates longer endurance, ultra-precise drilled hole location, and superior hole wall quality.

View product page ›

Series 460 / 480 Advanced Undercut Drills

Achieve excellent results from the 460/480 drills designed for superior hole wall quality and an undercut diameter to reduce cutting friction and temperature. Utilizing a thicker web for higher strength, these series can be used in a broad range of materials.

View product pages › View product brochure ›

Series 1735 Soft Laminate or Fine Metal Edge End Mill

Series 1735 End Mills designed to provide an ultra-fine edge finish on soft PCB laminate materials and metals that require flawless edges and cleanly cut fibers. The End Style allows surface milling and plunging.

View product pages ›

Series 2350 Fracture Reducing Router

The Series 2350 design combines the advantages provided by end mills for edge quality and the chipbreaker router for debris evacuation. In addition, these tools generally eliminate the requirement of entry material that is sometimes needed on this type of work when using conventional cutters.

View product pages ›
